Schneider TSXDEY32D2KC Discrete input module -32 current sink isolated - 24 V DC - 3.5 mA,TSXDEY32D2KC, Schneider
Schneider TSXDEY32D2KC Discrete input module -32 current sink isolated - 24 V DC - 3.5 mA
| range of product |
Modicon Premium Automation platform
|
|
|---|---|---|
| product or component type |
Discrete input module
|
|
| discrete input number |
32 current sink isolated conforming to EN/IEC 61131-2 type 1
|
|
| discrete input voltage |
24 V DC positive
|
|
| sensor power supply |
19...30 V
|
|
| discrete input current |
3.5 mA
|
| voltage state 1 guaranteed |
>= 11 V
|
|
|---|---|---|
| current state 1 guaranteed |
>= 3 mA
|
|
| voltage state 0 guaranteed |
<= 5 V
|
|
| current state 0 guaranteed |
<= 1.5 mA
|
|
| input impedance |
6300 Ohm at state 1
|
|
| response time |
<= 7 ms
4 ms |
|
| isalotion resistance |
< 10 MOhm 500 V DC
|
|
| power dissipation |
(1 W + 0.1 W x No of channels used)
|
|
| electrical connection |
HE-10 connector
|
|
| marking |
CE
|
|
| current consumption |
135 mA 5 V DC
160 mA 24 V DC |
|
| module format |
Standard
|
|
| product weight |
0.3 kg
|
| dielectric strength |
1500 V AC at 50/60 Hz
|
|
|---|---|---|
| standards |
73/23/EEC
89/336/EEC 92/31/EEC 93/68/EEC CSA C22.2 No 142 EN/IEC 61131-2 IEC 60664 UL 508 CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 213 Class I Division 2 Group C CSA C22.2 No 213 Class I Division 2 Group D |
|
| product certifications |
ABS
BV DNV GL LR RINA RMRS |
|
| ambient air temperature for operation |
0...60 °C
|
|
| ambient air temperature for storage |
-25...70 °C
|
|
| relative humidity |
10...95 % without condensation for operation
5...95 % without condensation for storage |
|
| operating altitude |
0...2000 m
|
|
| protective treatment |
Conformal coating Humiseal 1A33
TC |
|
| IP degree of protection |
IP20
|
|
| pollution degree |
2
|
Schneider TSXDEY32D2KC Discrete input module -32 current sink isolated - 24 V DC - 3.5 mA,TSXDEY32D2KC
- Brand: Schneider
- Product Code: TSXDEY32D2KC
- Availability: 1000
Tags: TSXDEY32D2KC
