Siemens 6AV2124-1QC02-0AX1 KP1500 Comfort 15.4 inch TFT,6AV2124-1QC0, Siemens

Siemens 6AV2124-1QC02-0AX1 KP1500 Comfort 15.4 inch TFT widescreen display, 16 Mio colors

Display 15.4 inch TFT widescreen display, 16 Mio colors

Resolution 1280 x 800 px

Control elements Touch screen

Membrane Keypad (28 keys),

36 function keys with LED

User memory 24 MB

Interfaces

2 x RJ 45 for PROFINET (with integrated switch)

1 x RJ 45 Ethernet for PROFINET (gigabit capable)

1 x RS 485/422 for PROFIBUS/MPI

2 x USB-host, 1 x USB- device

2 x SD card slot

Degree of protection IP 65, NEMA 4x (front if mounted) / IP 20 rear

Installation cutout 396 x 291 mm (W x H) 450 x 291 mm (W x H)

Fzont panel 415 x 310 mm (W x H) 483 x 310 mm (W x H)

Device depth 75 mm 75 mm

Software functions

Configuration software

WinCC Comfort (TIA Portal) or higher

Messages 6000

Message classes 32

Process pictures 750

Variables 4096

Vector graphics x

Bar graphics x

Curve diagrams f (t), f (x)

Recipes 500

Archiving 200

Visual Basic Scripts 200

Article No.: 6AV2124-1QC02-0AX1
