Altivar

EMC input filter

Altivar Process ATV900
Altivar Process ATV600

ATV630 wall mount, at 18.5 kW, 380...480 V
ATV630 wall mount, at 22 kW, 380...480 V
ATV630 wall mount, at 11 kW, 200...240 V
ATV650 wall mount, at 18.5 kW, 380...480 V
ATV650 wall mount, at 22 kW, 380...480 V
ATV930 wall mount, at 18.5 kW, 380...480 V
ATV930 wall mount, at 22 kW, 380...480 V
ATV930 wall mount, at 11 kW, 200...240 V
ATV950 wall mount, at 18.5 kW, 380...480 V
ATV950 wall mount, at 22 kW, 380...480 V

Radio interference input filter

50 A

8 W

Three phase

Terminal 16 mm² AWG 4

<= 150 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C2, 380...480 V
<= 300 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C3, 380...480 V
<= 150 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C2, 200...240 V
<= 300 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C3, 200...240 V
<= 50 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C1, 200...240 V
<= 50 m shielded motor cable 4 kHz conforming to EN/IEC 61800-3 category C1, 380...480 V

7.6 mA at 400 V 50 Hz TN
7.6 mA at 400 V 50 Hz TT

380...480 V
200...240 V

10 %

Shocks conforming to IEC 60721-3-3 class 3M4
Vibrations conforming to IEC 60721-3-3 class 3M4

90 mm

283 mm

165 mm

5.2 kg

IP20 mounting side by side
IP21 with kit VW3A47904

5...95 % without condensation conforming to IEC 61800-5-1

50...60 °C with current derating 1.5 % per °C
-10...50 °C without current derating

-40...70 °C

0...1000 m without current derating
1000...4000 m with current derating 1 % per 100 m

EN/IEC 61800-3
