Schneider TSXWMY100C Ethernet TCP/IP module - 10/100 Mbit/s - web server class D10 - Humiseal 1A33,TSXWMY100C, Schneider
Schneider TSXWMY100C Ethernet TCP/IP module - 10/100 Mbit/s - web server class D10 - Humiseal 1A33
| range of product |
Modicon Premium Automation platform
|
|
|---|---|---|
| product or component type |
Ethernet TCP/IP module
|
|
| physical interface |
RJ45 10BASE-T/100BASE-TX 1 twisted pair
|
|
| transmission rate |
10/100 Mbit/s
|
|
| communication service |
Modbus TCP messaging
SMTP e-mail notification SNMP agent SOAP XML Web (client/server) Uni-TE messaging |
|
| supply |
Via the power supply of the rack
|
|
| local signalling |
1 LED red collision detection (COL)
1 LED amber configuration status (STS) 1 LED green Ethernet network status (RUN) 1 LED red Ethernet port fault (ERR) 1 LED amber transmission activity (TX) 1 LED amber reception activity (RX) |
| communication port protocol |
Modbus TCP
Uni-Telway |
|
|---|---|---|
| maximum number of connections |
64
|
|
| web server |
Transparent ready class D10
|
|
| web feature |
Data Editor (via PC terminal)
FactoryCast configurable FactoryCast HMI active Rack viewer |
|
| memory description |
User web page size 8 MB
|
|
| marking |
CE
|
|
| product compatibility |
PL7 Pro
Unity Pro |
|
| current consumption |
360 mA 5 V DC
|
|
| module format |
Standard
|
|
| product weight |
0.34 kg
|
| standards |
CSA 1010-1
EN 61131-2 FM Class 1 Division 2 group A FM Class 1 Division 2 group B FM Class 1 Division 2 group C FM Class 1 Division 2 group D UL 508 |
|
|---|---|---|
| IP degree of protection |
IP20
|
|
| protective treatment |
Conformal coating Humiseal 1A33
|
|
| ambient air temperature for operation |
0...60 °C
|
|
| relative humidity |
10...95 % at 60 °C without condensation
|
