Schneider ATV312H018M2B Variable speed drive,ATV312H018M2, Schneider
Schneider ATV312H018M2B Variable speed drive ATV312 - 0.18kW - 0.6kVA - 24W - 200..240 V- 1-phase supply
| range of product |
Altivar 312
|
|
|---|---|---|
| product or component type |
Variable speed drive
|
|
| product destination |
Asynchronous motors
|
|
| product specific application |
Simple machine
|
|
| assembly style |
With heat sink
|
|
| component name |
ATV312
|
|
| motor power kW |
0.18 kW
|
|
| motor power hp |
0.25 hp
|
|
| [Us] rated supply voltage |
200...240 V (- 15...10 %)
|
|
| supply frequency |
50...60 Hz (- 5...5 %)
|
|
| network number of phases |
Single phase
|
|
| line current |
3 A for 200 V, 1 kA
2.5 A for 240 V |
|
| EMC filter |
Integrated
|
|
| apparent power |
0.6 kVA
|
|
| maximum transient current |
2.3 A for 60 s
|
|
| power dissipation in W |
24 W at nominal load
|
|
| speed range |
1...50
|
|
| asynchronous motor control profile |
Sensorless flux vector control with PWM type motor control
signal
Factory set : constant torque |
|
| electrical connection |
L1, L2, L3, U, V, W, PA, PB, PA/+, PC/- terminal 2.5 mm² AWG 14
|
|
| supply |
Internal supply for logic inputs at 19...30 V, <= 100 mA for
overload and short-circuit protection
Internal supply for reference potentiometer (2.2 to 10 kOhm) at 10...10.8 V, <= 10 mA for overload and short-circuit protection |
|
| communication port protocol |
CANopen
Modbus |
|
| IP degree of protection |
IP20 on upper part without cover plate
IP21 on connection terminals IP31 on upper part IP41 on upper part |
|
| option card |
CANopen daisy chain communication card
DeviceNet communication card Fipio communication card Modbus TCP communication card Profibus DP communication card |
