Schneider ABL8MEM24012 Regulated SMPS - 1 or 2-phase - 100..240 V AC - 24 V - 1.2 A

Main
range of product
Phaseo
product or component type
Power supply
power supply type
Regulated switch mode
input voltage
100...240 V AC phase to phase, terminal(s): L1-L2
100...240 V AC single phase, terminal(s): N-L1
120...250 V DC
output voltage
24 V DC
rated power in W
30 W
input protection type
Integrated fuse (not interchangeable)
power supply output current
1.2 A
output protection type
Against short-circuits
ambient air temperature for operation
-25...55 °C without
55...70 °C with
Complementary
input voltage limits
85...264 V
network frequency
47...63 Hz
inrush current
20 A
cos phi
0.5
efficiency
82 %
output voltage limits
22.2...28.8 V adjustable
power dissipation in W
6.6 W
current consumption
0.4 A at 240 V
0.65 A at 100 V
line and load regulation
+/- 3 %
residual ripple
250 mV
holding time
>= 10 ms at 100 V
>= 150 ms at 230 V
connections - terminals
Screw type terminals for input connection, connection capacity: 2 x 0.14...2 x 2.5 mm² AWG 26...AWG 14
Screw type terminals for output connection, connection capacity: 4 x 0.14...4 x 2.5 mm² AWG 26...AWG 14
marking
CE
mounting support
35 x 15 mm symmetrical DIN rail
Panel 2 screws, diameter : 4 mm
35 x 7.5 mm symmetrical DIN rail
operating position
Vertical
operating altitude
2000 m
output coupling
Parallel
Series
name of test
Harmonic current emission conforming to EN/IEC 61000-3-2
Conducted emissions on the power line conforming to EN 55022 Class B
Electrostatic discharges conforming to EN/IEC 61000-4-2
Emission conforming to EN 50081-1
Induced electromagnetic field conforming to EN/IEC 61000-4-6
Primary outage conforming to IEC 61000-4-11
Radiated electromagnetic field conforming to EN/IEC 61000-4-3
Radiated emissions conforming to EN 55022 Class B
Rapid transient conforming to IEC 61000-4-4
Surge conforming to EN/IEC 61000-4-5
status LED
1 LED green for output voltage
depth
59 mm
height
100 mm
width
54 mm
product weight
0.195 kg

Environment
product certifications
TUV 60950-1
CCSAus
CSA 22-2 No 950
RCM
KC
CULus 508
EAC
standards
CSA C22.2 No 60950-1
UL 508
environmental characteristic
EMC conforming to EN 55022 Class B
EMC conforming to EN 61000-6-3
EMC conforming to EN/IEC 61000-6-2
EMC conforming to EN/IEC 61204-3
Safety conforming to EN/IEC 60950-1
Safety conforming to SELV
IP degree of protection
IP20 conforming to EN/IEC 60529
ambient air temperature for storage
-40...70 °C
relative humidity
0...90 % during operation
0...95 % in storage
overvoltage category
Class II conforming to VDE 0106-1
dielectric strength
Between input and output
MTBF reliability
406032 H with MIL-HDBK-217F calculation method
