Hitachi SP12N002 4.8" Lcm Panel,SP12N002, Hitachi

Hitachi SP12N002 4.8" Lcm Panel

Panel Brand HITACHI

Panel Model SP12N002

Panel Size 4.8"

Panel Type FSTN-LCD, LCM

Resolution 256×64  Pixel FormatRectangle

Display Area120.29(W)×30.05(H) mm Bezel Opening124.3(W)×34.05(H) mm

Outline Size160(W)×68(H) ×12(D) mm SurfaceHard coating (3H)

Brightness90 cd/m² (Typ.) Contrast Ratio 20:1 (Typ.) (TM)

Viewing Angle40 (Typ.)(CR≥2, Φ2-Φ1) Left / Right / Up / DownDisplay ModeSTN, Black/White mode, Transmissive

Best View on6 o'clockResponse Time110/160 (Typ.)(Tr/Td)

Display Colors Monochrome  Lamp Type1 pcs CCFL , Without Driver

Frequency75Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC CircuitTouch ScreenWithout

Panel Weight-ApplicationIndustrial

Signal Interface8-bit parallel , 20 pins , Connector

Input Voltage5.0V (Typ.)

EnvironmentOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C ; Vibration Level: 2.0G (19.6 m/s²)

Write a review

Please login or register to review

Hitachi SP12N002 4.8" Lcm Panel,SP12N002

  • Brand: Hitachi
  • Product Code: SP12N002
  • Availability: 1000

Tags: SP12N002
